PRAKASH 1.0 HP HORIZONTAL MULTISTAGE PUMP PHMP4-30

Application Household Water supply Equipment support Pipeline Pressurization Garden Watering Vegetable Greenhouse watering Fish farming and poultry raising Industrial and mining Water Supply and drainage of enterprises High-Rise buildings Central air conditioner Centralized heating circulation system etc. Performance Range Flow : Up to 117 LPM Head: Up to 28m Speed 2900 rpm Power 0.55Kw Inlet /Outlet (Inch) : 1.25?x1? Motor Insulation Class :F Protection class : IP44 Built-in thermal protector for single phase motor Application Limits Manometric Suction Lift Up to 8m Liquid Temperature between -10°C to +105°C Ambient Temperature Up to +40°C
